| Free Air Delivery |
550CFM |
| Normal Working Pressure |
T200PSIG |
| Ambient Temperature Range |
5 - 52 ˚C |
| Air outlet valve with trolley (Wheeled) |
2 nos of 3/4" & 1 no of 2" |
| Air outley valve without trolley (Skid/ Rig) |
1 no of 2" |
| Engine make |
Ashok leyland |
| Rated engine power |
205(150.8)HP(kW) |
| Overall dimention with trolley (Wheeled) |
4080 X 1960 X 2200 L X B X H, MM |
| Overall dimention without trolley (Skid/ Rig) |
2850 X 1420 X 1650 L X B X H, MM |
| Dry weight of the Package with trolley (Wheeled) |
3000Kg |
| Dry weight of the Package without trolley (Skid/ Rig) |
2700Kg |
| Mounting type |
Wheeled/ Skid |
